4GV UN Approved Fibreboard Boxes
Description
4GV fibreboard boxes are UN approved combination packaging designed for the safe transport of dangerous goods with multiple inner packaging configurations under a single certification.
They are widely used across pharmaceutical, chemical, laboratory, and logistics industries where flexibility, compliance, and efficiency are critical.
What is 4G packaging?
4GV packaging allows different inner packaging types including bottles, jars, jerrycans and bags to be shipped together within one certified outer box.
Reduced packaging complexity
Fewer packaging SKUs
Full compliance when correctly configured
Available 4G Box Sizes (Full Stock Range)
Below is our standard range of 4GV UN approved fibreboard boxes available from stock.
Additional sizes and configurations are available depending on your requirements.
4GV box Size Table
Product Code | Inner Dimensions (mm) | Max Gross Weight | Boxes per Pallet |
4GV3THP | 115 x 115 x 270 | 2.1 kg | 1800 |
4GV1THP | 155 x 155 x 265 | 3.9 kg | 1120 |
4GV2THP | 264 x 134 x 308 | 3.9 kg | 480 |
4GV5 | 272 x 218 x 298 | 5 kg | 280 |
4GV6 | 172 x 152 x 225 | 5.8 kg | 900 |
4GV6.3THP | 150 x 150 x 273 | 6.3 kg | 720 |
4GV7 | 316 x 248 x 310 | 7.9 kg | 240 |
4GV12.2 | 193 x 194 x 301 | 12.2 kg | 360 |
4GV13T | 272 x 197 x 295 | 13.2 kg | 300 |
4GV17.9 | 270 x 250 x 350 | 17.9 kg | 300 |
4GV20.3T | 390 x 296 x 327 | 20.3 kg | 150 |
4GV20.6 | 310 x 279 x 272 | 20.6 kg | 300 |
4GV22 | 592 x 389 x 304 | 22 kg | 70 |
4G BOX BATTERY | 450 x 210 x 140 | 23.8 kg | 120 |
4GV23T | 426 x 313 x 300 | 23.2 kg | 150 |
4GV30THP | 568 x 373 x 430 | 30 kg | 75 |
4GV31.2 | 400 x 300 x 300 | 31.2 kg | 150 |
4GV34 | 604 x 403 x 510 | 34 kg | 70 |
4GV34.4 | 510 x 370 x 270 | 34.4 kg | 150 |
4GV35.6T | 386 x 395 x 425 | 35.6 kg | 150 |
4GV49.8 | 400 x 400 x 400 | 49.8 kg | 75 |
4GV55 | 562 x 367 x 452 | 55 kg | 70 |
4GV62.5 | 550 x 401 x 400 | 62.5 kg | 35 |
4GV89.5 | 702 x 402 x 504 | 89.5 kg | 35 |
4GV160 | 770 x 570 x 550 | 160 kg | 70 |
4GV245 | 1175 x 770 x 740 | 245 kg | 70 |
4GV259.6THP | 1166 x 771 x 604 | 259.6 kg | 70 |
4GV517 | 1170 x 765 x 800 | 517 kg | 70 |
Required for Compliance
Cross weave tape for sealing
Vermiculite or Absorbent pads for liquid containment, cushioning and absorption
These are essential components of a compliant packaging system.
Typical Applications
Pharmaceutical products
Laboratory chemicals
Hazardous liquid shipments
Mixed dangerous goods consignments
Dangerous Goods Repacking operations
Smaller samples
Common mistakes
Incorrect absorbents
Improper sealing
Overloading boxes
Incorrect inner packaging combinations
Speak to an Expert
We will help you select the correct box, configuration and consumables to ensure full compliance.
Speak to an Expert today
